Are you looking for the perfect PE coated paper for your cup-making business? This guide answers your most important questions about PE coated paper rolls, sheets, and specifications—helping you make smart choices that save money and improve quality. It will help you make smart choices that save you money and improve quality, whether you're a coffee shop owner, cup manufacturer, or beverage company.
Polyethylene (PE) coated paper is the material used to make most disposable cups. It consists of everyday paper combined with a thin plastic layer that prevents leaks and keeps cups strong.
In the extrusion coating process, melted PE is applied evenly to paper under heat and pressure. This creates a continuous plastic barrier that bonds tightly to the paper surface.
The PE coating stops hot liquids from seeping through and prevents cold drinks from making the cup walls wet and soft.
PE coating costs less than plant-based alternatives (PLA) while offering better moisture protection, heat resistance up to 95 °C, and reliable printing results.
Choosing rolls or sheets affects how you print, cut, and form cups:
Most coffee chains and large paper cup manufacturers prefer rolls because they cut down on downtime and labor costs.
Highlights:
Suitable for high-speed cup machines that feed paper continuously with no need to stop and reload individual sheets.
Works with flexographic printing, which uses flexible rubber plates and water-based inks for bright, food-safe designs.
Typical waste: 9–13% of material is trimmed or unused.
Boutique brands may use sheets for custom-branded limited editions.
Highlights:
Better for small batches or custom shapes because you can cut each sheet individually.
Ideal for offset printing, which delivers sharp, photo-quality images with oil- or specialty inks.
Typical waste: 14–16% due to edge trims and test prints.
Kindeal Paper supplies both formats with customized options. Share your application and machine details, and our experts will recommend the most efficient option.
The number of PE layers determines how much moisture protection you get:
Best for hot drinks like coffee and tea in cups from 2.5 to 16 ounces.
The outer side remains paper-like for easy printing and branding.
Needed for cold drinks, iced coffee, or frozen treats in cups from 9 to 32 ounces.
Prevents both interior leaks and exterior condensation drips.
If you find your one-sided PE-coated paper cups get soggy or weak in use, switching to double PE coating usually fixes such problems.
What Makes a PE Coated Paper Supplier Trustworthy?
Sometimes your single PE coated paper cups don't work well not because they only have one side coated, but because the coating itself is terrible. So choosing quality supplies from a trusted supplier is vital. Before you order, check your supplier’s credentials and capabilities:
Be sure that your PE coated paper supplier satisfies the highest criteria for food safety and sustainability. The essentials include:
FDA compliance proves the paper and PE coating are safe for direct food contact.
FSC certification ensures the paper comes from responsibly managed forests.
Always ask for current credentials. Expired certifications could mean a compliance issue. Reliable manufacturers like Kindeal Paper give you comprehensive FDA certification documents with every batch, so you know that all the paper that touches your food or drink is safe. It also keeps FSC accreditation by using certified supplier chains to show that it follows sustainable forestry practices.
Technical Capabilities
Trusted suppliers like Kindeal Paper demonstrate technical excellence through measurable performance specifications that directly impact your product success:
Precision coating specifications with guaranteed GSM ranges and thickness consistency that match your exact cup-forming requirements
Verified barrier performance with documented water resistance and oil penetration properties suitable for your beverage and food applications
Defined thermal and sealing parameters with recommended temperature ranges and heat-sealing guidelines to ensure smooth processing on your production equipment
Quality Control
Leading suppliers like Kindeal Paper implement comprehensive quality control systems that go beyond basic certification:
Raw material inspection at arrival, including tests for physical properties, moisture content, and heavy metal content
In-process monitoring with automated coating thickness control and real-time quality adjustments
Finished product testing including barrier performance, adhesion strength, and food safety compliance
Traceability systems that track materials from sourcing through delivery for rapid issue identification
Understanding cupstock specifications prevents costly failures and ensures cups perform perfectly for your customers. Each specification directly impacts cup strength, leak resistance, and user experience.
Hot Beverage Cup Specifications
Small hot drinks (2.5-4 oz espresso, cortado) typically require:
Base paper: 150-180 GSM for cost efficiency while maintaining adequate strength
PE coating: Single PE 10-15 GSM on interior surface only
Temperature rating: Safe to 90°C (covers typical coffee serving temperatures)
Standard hot drinks (6-12 oz coffee, tea, hot chocolate) usually use:
Base paper: 170-230 GSM balances cost and insulation
PE coating: Single PE 12-18 GSM for enhanced barrier performance
Temperature rating: Safe to 95°C for extra safety margin
Large hot drinks (16+ oz lattes, large coffee) often demand:
Base paper: 230-320 GSM provides structural integrity for heavy liquid volume
PE coating: Single PE 15-20 GSM for premium barrier protection
Temperature rating: Safe to 95°C with enhanced structural stability
Medium cold drinks (9-12 oz iced coffee, juice, soda) typically use:
Base paper: 190-230 GSM for condensation resistance
PE coating: Double PE 12-20 GSM each side for total moisture protection
Temperature range: -18°C to 90°C handles ice and room temperature liquids
Large cold drinks (16-24 oz iced beverages, smoothies) often require:
Base paper: 230-280 GSM supports larger liquid volumes
PE coating: Double PE 15-25 GSM each side for enhanced durability
Temperature range: -18°C to 95°C with superior condensation management
Extra-large cold drinks (32 oz fountain drinks, family sizes) usually need:
Base paper: 250-330 GSM for maximum structural integrity
PE coating: Double PE 18-30 GSM each side for heavy-duty protection
Temperature range: -18°C to 95°C with maximum condensation resistance
Single-serve ice cream (4-8 oz portions) usually uses:
Base paper: 200-280 GSM for freezer stability
PE coating: Double PE 15-25 GSM each side with freezer-grade formulation
Special requirements: Enhanced low-temperature flexibility prevents cracking
Large ice cream containers (12+ oz family sizes, gelato) often require:
Base paper: 280-350 GSM for premium structural strength
PE coating: Double PE 20-30 GSM each side for maximum freezer performance
Special features: High-gloss finish options available for premium presentation
Soup and hot food containers typically require:
Base paper: 250-320 GSM for hot liquid and solid food
PE coating: Single PE 18-25 GSM with enhanced grease resistance
Temperature rating: 95°C with extended thermal stability
Sample and tasting cups (2.5 oz) often use:
Base paper: 140-160 GSM for cost optimization
PE coating: Single-side 8-12 GSM for basic protection
Temperature rating: 85°C, adequate for brief contact
How to Specify Your Requirements for Supply Recommendation
Professional suppliers like Kindeal Paper offer free consultations where you can get a tailored PE coated paper solution recommendation. Just provide your application details:
Cup size range (oz) and primary beverage type (hot/cold/frozen)
Expected use duration (quick consumption vs. extended holding)
Environmental conditions (standard, high humidity, freezer storage)
Quality tier (economy, standard, premium positioning)
Production volume (affects minimum coating thickness options)
What About the Printing and Converting Options for PE Coated Paper Supplies?
Selecting the right printing method and converting process directly impacts your cup quality, production efficiency, and brand presentation. Professional manufacturers like Kindeal Paper typically offer these services.
Why Order Printing with Your PE Coated Paper?
Ordering printing services with your PE coated paper streamlines your entire supply chain through single-supplier coordination, ensuring guaranteed color results and unified quality accountability.
You can get flexographic printing for PE coated paper rolls:
Uses flexible rubber plates—ideal for simple logos and single-color designs.
Prints 6 water-based, food-grade colors.
Costs around $40–70 per color plate; 9–13% material waste.
For PE coated paper sheets, offset printing is available:
Digital plates produce sharp, multi-color, photographic-quality images.
Prints up to 8 colors with standard oil-based or pricier food-grade inks.
Lower plate cost but higher material waste (14–16%).
Why Order Cup Fans and Bottom Rolls?
Ordering pre-cut paper cup fans and bottom rolls eliminates your need for expensive flexographic printing and die-cutting equipment.
You can order cup fans for precision sidewall components:
Die-cut side panels with ±1mm tolerance for leak-proof assembly
Custom fan shapes optimize material usage and accommodate multiple cup sizes
Ready-to-use pieces eliminate your die-cutting equipment and labor costs
For cup bottoms, bottom rolls provide exact base materials:
Narrow strips (40-140mm) engineered for perfect heat-sealing
Multiple width options accommodate cup sizes from 4oz to 32oz
Consistent coating thickness ensures reliable bottom-to-sidewall bonding
Ready to Source PE Coated Paper That Meets Your Exact Needs?
Follow these steps to launch your cup production with confidence:
Assess your requirements: Cup sizes, hot vs. cold applications, print needs
Request samples: Test with your actual beverages and equipment
Verify certifications: Ensure FDA compliance and food safety standards
Compare total costs: Factor in waste reduction and efficiency gains
Start with a trial order: Test production compatibility before large commitments
With over 30 years of expertise in PE coated cup paper manufacturing, Kindeal Paper delivers tailored solutions—roll or sheet, single or double PE coating, and custom printing options—to meet every cup-making need. Contact Kindeal Paper today for a personalized consultation, free samples, and transparent quotes.
Interested in more applications utilizing PE coated paper? Check our foundational blog, "What Is PE Coated Paper and What Are Its Practical Uses?"
